| Zahlungsart: | L/C,T/T,D/P |
| Incoterm: | FOB,CFR,CIF,EXW |
| Transport: | Ocean,Land,Express |
| Hafen: | Tianjin,Shanghai,Qingdao |
Modell: Q195 Q235 Q345
Standard: bs, GB, ASTM, JIS, LÄRM, API
Material: Q195-Q345
Schnittform: Quadrat
Herkunftsort: China
Anwendung: Strukturrohr, Flüssigkeitsrohr
Produktionsprozess: Warmgewalzt
Zertifizierung: Bsi, ce, UL, API
Ob Legierung: Nicht legiert
Toleranz: ± 1%
Kategorie: Quadratische Röhren, Geschweißtes Stahlrohr
Verarbeitungsservice: Biegen, Abwickeln, Stanzen, Schneiden, Schweißen
Specification: 10X10-500X500mm
Dicke: 0.5mm-100mm or Customizable
Length: 3m 5m 6.5m 8m 12.5m 13m 14m 18m or Customizable
Surface: Black Painted Galvanized Color-Coated Oiled
| Verkaufseinheiten | : | Ton |
| Pakettyp | : | Bündelung und seetüchtiges Packinge |
| Bildbeispiel | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
Mit einer jährlichen Leistung von 15 Millionen Tonnen ist unser Firmenstahl das größte ERW -Quadratrohr, ein rechteckiges Rohr, ein hohes Rohr, ein verzinktes Rohr und den Hersteller von Spiralschweißrohr in China. Der Jahresumsatz erreichte 5 Milliarden US -Dollar. Unsere Firmenstahl verfügt über 59 schwarze Rohrproduktionslinien, 10 verzinkte Rohrproduktionslinien, 3 spiralgeschweißte Rohrproduktionslinien, 1 JCOE LSAW Steel Rohrproduktionslinie. Quadratrohr 10 * 10 * 0,5 mm bis 1000 * 1000 * 60 mm, rechteckiges Stahlrohr 10 * 15 * 0,5 mm bis 800 * 1100 * 60 mm, Spiralrohr Ø 219-1420 mm können aus der Streckgrenze aus q (s) 195 MPa bestehen. zu Q (s) 690 MPa. Unser Unternehmen kann quadratische rechteckige Röhrchen gemäß ASTM A500/A501, JIS G3466, EN10219, EN10210, BV, DIN2240 und AS1163, GB/T9711, GB/T3091, GB/T3094, GB/T6728 usw.
und unsere Mühle wurde durch BC1, EPD, PhD, ISO9001, ISO14001, ISO45001 zertifiziert. Unser Unternehmen Steel verfügt über das größte Stahlrohrinventar in China, das die dringende Kaufnachfrage von Kunden erfüllen kann. Begrüßen Sie alle, die Sie mit uns kontaktieren können, und besuchen Sie unsere Fabrik online oder offline.
Produktspezifikation
| Product Name | Carbon Steel Square Pipe; Carbon Steel Square Tube |
| Standard |
GB5310-2009, GB3087-2008, GB6479-2013, GB9948-2013, GB/T8163-2008, GB8162-2008, GB/T17396-2009 EN10216-5, EN10217-7, DIN17456, DIN 17458 JIS G3463, JIS G3119, JIS G3446, JIS G3218, JIS G3258, JIS G3448, JIS H4631 |
| Outer Diamater |
1) Round Pipe: 8mm - 680mm 2) Square Pipe: 10mm*10mm - 500mm*500mm 3) Rectangular Pipe: 10mm*20mm -500mm*450mm |
| Wall-Thickness | 0.5mm-100mm or Customized |
| Length | 1m, 1.8m, 2m, 3m, 4m, 5m, 5.8m, 6m, 9m, 10m, 11.8m, 12m or Customized |
| Square Pipe Size | 16×16×0.4~1.5 ; 18×18×0.4~1.5 ; 20×20×0.4~1.5 ; 25×25×0.6~2.0 ; 30×30×0.6~4.0 ; 34×34×1.0~2.0 ; 35×35×1.0~4.0 ; 38×38×1.0~4.0 ; 40×40×1.0~4.5 ; 44×44×1.0~4.5 ; 45×45×1.0~5.0 ; 50×50×1.0~5.0 ; 60×60×1.5~5.0 ; 70×70×2.0~6.0 ; 75×75×2.0~6.0 ; 80×80×2.0~6.0 ; 85×85×2.0~6.0 ; 95×95×2.0~8.0 ; 100×100×2.0~8.0 ; 120×120×4.0~8.0 ; 150×150×6.0~10.0 ; 180×180×6.0~12.0 ; 200×200×6.0~30.0 ; 220×220×6.0~30.0 ; 250×250×6.0~30.0 ; 280×280×6.0~30.0 ; 300×300×8.0~30.0 ; 320×320×8.0~30.0 ; 350×350×8.0~30.0 ; 380×380×8.0~30.0 ; 400×400×8.0~30.0 ; 420×420×10.0~30.0 ; 450×450×10.0~30.0 ; 480×480×10.0~30.0 ; 500×500×10.0~30.0 |
| Rectangular Tube Size | 10×20×0.6~1.5 ; 14×21×0.6~1.5 ; 15×30×1.5~1.5 ; 15×38×0.6~1.5 ; 20×30×0.6~2.0 ; 20×40×0.8~2.0 ; 20×50×1.0~2.0 ; 22×35×0.9~2.0 ; 25×40×0.9~3.75 ; 25×65×1.0~2.0 ; 30×40×1.0~3.75 ; 30×45×1.0~3.75 ; 30×50×1.0~4.0 ; 30×60×1.0~4.5 ; 40×50×1.0~4.5 ; 40×60×1.0~5.0 ; 40×80×1.5~5.0 ; 40×100×2.0~5.0 ; 50×60×2.0~5.0 ; 50×80×2.0~5.0 ; 50×100×2.0~8.0 ; 60×80×2.0~6.0 ; 80×100×2.0~8.0 ; 120×60×2.5~10.0 ; 120×80×2.5~10.0 ; 150×100×2.5~12.0 ; 180×150×2.5~12.0 ; 200×100×4~12.0 ; 200×150×4~12.0 ; 250×150×6~12.0 ; 250×100×6~12.0 ; 250×200×6~30.0 ; 300×150×6~30.0 ; 300×200×6~30.0 ; 300×250×6~30.0 ; 400×250×8~30.0 ; 400×300×8~30.0 ; 450×200×8~30.0 ; 450×250×8~30.0 ; 400×300×8~30.0 ; 400×350×8~30.0 ; 500×200×10~30.0 ; 500×250×10~30.0 ; 500×300×10~30.0 ; 500×350×10~30.0 ; 500×400×10~30.0 ; 500×450×10~30.0 |
| Surface | Galvanized, PVC, Black-Painting, Color-Painting, Transparent-Oil, Anti-Rust-Oil, Black-Varnish, 2PE, 3PE, Epoxy-Coating, BE, PE |
| Technique | Hot Rolled, Cold Drawn, Forging, Seamless or Welded |
| Shape | Round, Square, Oval, Rectangular, Welded, Elliptical, Triangular, Hexagonal, Octagonal, Irregular, Special Shapes or Customized |
| Pipe Ends |
1) Plain 2) Beveled 3) Threaded with coupling and plastic cap |
| Deep Processing | Oiled, Painted, Galvanized, Powder Coating, Shrink Head, Pressure Groove, Welding Head, Punching, Threaded With Coupling and Plastic Cap |
| Material-1 |
ASTM: A105, A106, A106B, A106C, A178, A179, A192, A210, A213, A249, A268, A269, A270, A312, A333, A335, A358, A409, A511, A519, A53, A53A, A53B, A554, A778, A790, A928, B338, B673, B674, B675, B676, B677, B690, 370WP91, WP1, WP2, Gr.B, API5L ASME: B36.19, B36.10 SAE1018, SAE1020, SAE1518, SAE1045 JIS: S10C, S20C, S25C, S35C, S45C, S55C, STKM11A, STKM12A, STKM12B, STKM12C, STKM13A, STKM13B, STKM13C, SCr420, SCr440, SCM415, SCM420 DIN: C10, CK10, C22, CK22, C35, CK35, C45, CK45, CF53 GB/T: 10#, 20#, 35#, 45#, 55#, Q195, Q215, Q235A, Q235B, Q235C, Q345A, Q345B, Q345C |
| Material-2 |
16Mn, 19Mn5, 20Cr, 40Cr, 20Mn2, Cr5Mo, 12CrMo, 15CrMo, 20CrMo, 28CrMo, 30CrMo, 35CrMo, 42CrMo, 12Cr1MoV, Cr5Mo, 30CMo, 20MnG, 25MnG, 15CrMoG, 12Cr1MoVG, 10CRM0910, 20CrMnTi, 40MnMoV, ZF6, 16MnCr5, 20MnCr5, 38Mn2V, 09CrCuSb(ND), 27SiMn, SS400 20Cr4, 41Cr4, 15CrMo4, 25CrMo4, 35CrMo4, 42CrMo4, 16MnCr5, 10CrMo910, 13CrMo44 C10/CK10, C22/CK22, C35/CK35, C45/CK45, S20C, S40C 1010, 1020, 1026, 1035, 1045, 1050, 4130, 4135, 4140, 5120, 5140 STP, API, 5L, CF53, SCM432, SCRRM3, SCM4, SAE1018, SAE1020, SAE1045 X42, X46, X52, X56, X60, X65, X70, X80, X100, H40, J55, K55, N80-1, N80-Q, L80-1, L80-9Cr, L80-13Cr St37, St37.0, ST37-2, St37.2, St35, St35.4, ST35.8, St42, St45, St52, St52.4, ST35, STP, STPT42, STB42, STS42, STPT49, STS49 G38, G42, J55, K55, L80, N80, P1, P2, P5, P9, P11, P12, P22, P91, P92, P110, T1, T2, T5, T9, T11, T12, T22, T23, T91,T92 Grade A, Grade B, Grade C, Gr.A, Gr.B, GR.1, GR.3, GR.6, GR.7 |
| Application |
1) Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe, Oil/Gas Drilling, Food/Beverage/Dairy Products, Machinery Industry, Chemical Industry, Mining, Construction Decoration, Special Purpose 2) Low and Middle Pressure Fluid Pipeline, Electric Industry, Drilling, shipbuilding, Fertilizer Equipment and Pipeline structure, Petrochemical, Pharmaceutical Industry 3) Agriculture Equipment Pipe, Water and Gas Pipe, Greenhouse Pipe, Scaffolding Pipe, Building Material Tube, Furniture Tube, Low Pressure Fluid Tube, Oil Pipe, Fence, Greenhouse, Door Pipe, Greenhouse 4) Widely Used in Scaffolding Construction Which is Much Cheaper and Convenient |
| Package | Packed in bundles with 6-8 pcs steel strips, and wrapped with waterproof cloth |
| Lead Time |
Delivery of spot products within 2-3 days after receiving the deposit Customized products delivered within 7-10 days |
| Payment Terms | 30% T/T in advance, 70% T/T 70% L/C at sight balance before shipment |
|
REGULAR SIZE
|
||
|
SIZE (OUTER DIAMETER)
|
WALL THICKNESS
|
LENGTH
|
|
20x20 / 25x25
|
1.2MM --2.75MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
30x30 / 20x40 / 30x40 / 25x40
|
1.2MM -- 3.5MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
40x40 / 50x50
30x50 / 25x50 / 30x60 / 40x60
|
1.2MM -- 4.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
60x60 / 50x70 / 40x80 / 40x50
|
1.2 MM -- 5.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
70x70 / 60x80 / 50x80 / 100x40 / 50x90
|
1.5MM -- 5.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
75x75 / 80x80 / 90x90
60x100 / 50x100 / 120x60 / 100x80 / 60x90
|
1.5MM -- 7.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
100x100 / 120x80
|
1.8MM -- 7.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
120x120 / 130x130
180x80 / 160x80 / 100x150 / 140x80 / 140x60
|
2.5MM -- 10.0 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
140x140 / 150x150 / 100x180 / 200x100
|
2.5MM -- 10.0 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
160x160 / 180x180 / 200x150
|
3.5MM -- 11.0 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
200x200 / 250x150 / 100x250
|
3.5MM -- 11.0 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
250x250 / 250x200 / 300x150 / 300x200
|
4.5MM -- 15.0 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
300x300 / 350x200 / 350x250 /300x150
|
4.5MM -- 15.0 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
350x350
350x300 / 450x250 / 400x300 / 500x200
|
4.5MM -- 15.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
|
400x400 / 280x280
450x300 / 450x200 / 400x350 / 400x250 / 500x250 / 500x300
|
4.5MM -- 15.75 MM
|
6M IN STOCK (OR CUSTOMIZED)
|
Warenpräsentation
Wir können unterschiedliche Größen, Formen, Dicken, Breiten und Materialien entsprechend Ihrer Anforderung s produzieren
